Residential Energy Storage Inverters

Ideal for solar energy storage, home battery backup, and off-grid power solutions, it supports sustainable living and maximizes solar efficiency.

Product Parameters

X3-GRD-300K-HV
X3-GRD-320K-HV
X3-GRD-333K-HV
X3-GRD-350K-HV

X3-GRD-300K-HV
- PV INPUT

  Max. recommended PV array power
  450 kWp
  Operating voltage range
  500 ~ 1500 d.c. V
  No. of MPP trackers / strings per MPP tracker 6 / 5
  Max. input current per MPPT 75 d.c. A
- AC INPUT & OUTPUT (ON-GRID)

  Rated output apparent power
  300 kVA
  Rated AC voltage 3W / PE, 800 a.c. V
- GENERAL

  Ingress protection IP66
  Dimensions (W × H × D)
  1225 x 825.5 x 369.1 mm
  Net Weight < 130 kg
  Cooling concept Smart air cooling
X3-GRD-320K-HV
- PV INPUT

  Max. recommended PV array power
  480 kWp
  Operating voltage range
  500 ~ 1500 d.c. V
  No. of MPP trackers / strings per MPP tracker 6 / 5
  Max. input current per MPPT 75 d.c. A
- AC INPUT & OUTPUT (ON-GRID)

  Rated output apparent power
  320 kVA
  Rated AC voltage 3W / PE, 800 a.c. V
- GENERAL

  Ingress protection IP66
  Dimensions (W × H × D)
  1225 x 825.5 x 369.1 mm
  Net Weight < 130 kg
  Cooling concept Smart air cooling
X3-GRD-333K-HV
- PV INPUT

  Max. recommended PV array power
  499.5 kWp
  Operating voltage range
  500 ~ 1500 d.c. V
  No. of MPP trackers / strings per MPP tracker 6 / 5
  Max. input current per MPPT 75 d.c. A
- AC INPUT & OUTPUT (ON-GRID)

  Rated output apparent power
  333 kVA
  Rated AC voltage 3W / PE, 800 a.c. V
- GENERAL

  Ingress protection IP66
  Dimensions (W × H × D)
  1225 x 825.5 x 369.1 mm
  Net Weight < 130 kg
  Cooling concept Smart air cooling
X3-GRD-350K-HV
- PV INPUT

  Max. recommended PV array power
  525 kWp
  Operating voltage range
  500 ~ 1500 d.c. V
  No. of MPP trackers / strings per MPP tracker 6 / 5
  Max. input current per MPPT 75 d.c. A
- AC INPUT & OUTPUT (ON-GRID)

  Rated output apparent power
  350 kVA
  Rated AC voltage 3W / PE, 800 a.c. V
- GENERAL

  Ingress protection IP66
  Dimensions (W × H × D)
  1225 x 825.5 x 369.1 mm
  Net Weight < 130 kg
  Cooling concept Smart air cooling
